Spin Flash Dryer(SFD) is an excellent and advanced industrial drying solution for continuous drying of wet cakes/pastes/filter cakes/slurries and high moisture materials. It is a mechanical dispersion and hot air drying technology that provides fast heat transfer, uniform drying and uniform final product quality.
We are a trusted Spin Flash Dryer Supplier India and Custom Spin Flash Dryer Manufacturer and design highly efficient drying systems for various industries including Pharmaceuticals, Chemicals, Food Processing, Minerals, Pigments, Specialty Materials etc. Our Industrial Spin Flash Dryer designed for high-performance, energy-efficient, and trouble-free operation under rigorous processing conditions.
The wet material is fed into the drying chamber via a controlled feeding system where the material is mechanically agitated at high speeds to break up any lumps and ensure adequate mixing with the hot air. The heat and moisture are exchanged rapidly, transforming the moist feed into a fine dry powder in seconds. The dried particles are then separated by cyclone separators, bag filters or any other separation system.
Solutions are available such as GMP Spin Flash Dryer, Pharma Spin Flash Dryer, Stainless Steel Spin Flash Dryer, Chemical Spin Flash Dryer, and Closed Loop Spin Flash Dryer, which can be customized depending on the product characteristics, process requirements, safety measures, and industry applications.
| Specification | Diameter (mm) | Evaporative Capacity (kgH2O/h) | Installed Power (kw) | Height (m) | Area (m*m) | Temperature (°C) | Others |
|---|---|---|---|---|---|---|---|
| GEO-SFD-300 | Φ300 | 20~50 | 2.2~5.5 | 4 | 3.8*2.7 | 120~350 (High temperature flash can reach 550) | Heat source: gas, steam, electricity, coal, oil, etc. |
| GEO-SFD-500 | Φ500 | 30~100 | 5.5~7.5 | 5 | 4*3 | 120~350 (High temperature flash can reach 550) | Heat source: gas, steam, electricity, coal, oil, etc. |
| GEO-SFD-600 | Φ600 | 40~200 | 5.5~7.5 | 6 | 4.3*3.2 | 120~350 (High temperature flash can reach 550) | Heat source: gas, steam, electricity, coal, oil, etc. |
| GEO-SFD-800 | Φ800 | 60~600 | 11~22 | 6.5 | 4.5*3.5 | 120~350 (High temperature flash can reach 550) | Heat source: gas, steam, electricity, coal, oil, etc. |
| GEO-SFD-1000 | Φ1000 | 100~1000 | 11~22 | 7.5 | 4.8*3.8 | 120~350 (High temperature flash can reach 550) | Heat source: gas, steam, electricity, coal, oil, etc. |
| GEO-SFD-1200 | Φ1200 | 150~1300 | 11~22 | 8 | 5*4 | 120~350 (High temperature flash can reach 550) | Heat source: gas, steam, electricity, coal, oil, etc. |
| GEO-SFD-1250 | Φ1250 | 150~1400 | 15~18.5 | 8 | 5*4 | 120~350 (High temperature flash can reach 550) | Heat source: gas, steam, electricity, coal, oil, etc. |
| GEO-SFD-1300 | Φ1300 | 180~1400 | 15~45 | 8.5 | 5.1*4.1 | 120~350 (High temperature flash can reach 550) | Heat source: gas, steam, electricity, coal, oil, etc. |
| GEO-SFD-1400 | Φ1400 | 200~1600 | 15~45 | 9 | 5.3*4.3 | 120~350 (High temperature flash can reach 550) | Heat source: gas, steam, electricity, coal, oil, etc. |
| GEO-SFD-1600 | Φ1600 | 250~2500 | 30~45 | 9.5 | 5.5*4.5 | 120~350 (High temperature flash can reach 550) | Heat source: gas, steam, electricity, coal, oil, etc. |
| GEO-SFD-1800 | Φ1800 | 300~2500 | 30~75 | 10 | 6*5 | 120~350 (High temperature flash can reach 550) | Heat source: gas, steam, electricity, coal, oil, etc. |
| GEO-SFD-2000 | Φ2000 | 400~3200 | 45~75 | 11 | 6.5*5.5 | 120~350 (High temperature flash can reach 550) | Heat source: gas, steam, electricity, coal, oil, etc. |
| GEO-SFD-2400 | Φ2400 | 500~4000 | 45~90 | 12 | 7*6 | 120~350 (High temperature flash can reach 550) | Heat source: gas, steam, electricity, coal, oil, etc. |
Note: Specifications may vary based on product characteristics, moisture content, drying capacity, temperature requirements, heat source, and customized process design.
Combining mechanical dispersion technology with high velocity hot air, the Spin Flash Dryer is engineered to offer fast and uniform drying. It guarantees efficient heat and mass transfer which enables the rapid removal of moisture from wet cakes, pastes and granular materials. This enables them to obtain a uniform quality of the product and a short drying period.
Spin Flash Drying System can be operated continuously, which is suitable for large-scale production requirements in industrial production. A controlled feeding mechanism guarantees the material's steady feed into the drying chamber. This increases productivity, minimizes downtime and ensures drying uniformity.
A special rotor and drying chamber enable efficient processing of sticky, viscous and high-moisture materials. When the product is broken up by mechanical agitation, it enhances product-hot air contact and reduces the formation of lumps. This will provide smooth drying of the materials that are hard to handle without losing final product quality.
The high speed mechanical action that occurs in the dryer helps to control particle size as larger particles are broken during drying. The system classifies only fine particles which have been dried properly to advance for collection. This helps achieve uniform powder characteristics as per process requirements.
The vertical and compact design of the Industrial Spin Flash Dryer minimizes space requirements while ensuring high drying efficiency. It's a streamlined design which makes it suitable for facilities that have minimal floor space. The system will work very well with no need for large processing areas.
The Spin Flash Dryer is designed to operate with the best possible use of heat and with minimum loss of energy during use. Fast airflow distribution and drying speed minimizes total power consumption. This leads to reduced operating costs and consistent drying results.
The air temperature, rotor speed, feed rate and residence time can be varied according to the material properties and production requirements. This versatility enables the dryer to operate effectively with various product categories. Desired moisture levels and product quality are achieved with customized settings.
The GMP Spin Flash Dryer and Stainless Steel Spin Flash Dryer are built according to hygienic standards for use in pharmaceutical, food and high purity applications. Smooth internal surfaces minimize the risk of contamination and streamline cleaning. The design is conducive to safe and quality processing.
The Closed Loop Spin Flash Dryer can be used for solvent based and sensitive materials that require controlled processing conditions. It aids in better solvent recovery, less emissions, and a safer working environment. The enclosed system also reduces the risk of exposure to and contamination of the product.
Powder recovery is effectively achieved by using an efficient cyclone separator, bag filter and dust collection system. These components provide optimum product collection and clean exhaust air treatment. Good separation system, which contributes to overall process efficiency.
The Pharma Spin Flash Dryer is used across the industry for drying pharmaceutical intermediates, API materials and products sensitive to temperature, while preserving product quality and process hygiene.
Chemical Spin Flash Dryer is an efficient machine for processing different chemical powders, pigments, polymers, fertilizers and other specialty chemical products.
For the drying of food ingredients and powders requiring controlled drying, consistency of quality and hygienic processing.
Perfect for drying pigments, dyes and colour based material, producing uniform particle quality and moisture reduction.
It is suitable for mineral powders, clays and inorganics processing with high efficiency of drying.
Used for drying ceramic powders and raw materials requiring controlled moisture levels before further processing.
For use in the drying of polymer powder, plastic additives and specialty materials.
Facilitates pesticide, fertiliser and agricultural chemical product drying without compromising product quality.
Spin Flash Dryer is a widely used dryer for drying wet cake obtained from filtration processes like filters and settling ponds. It will remove moisture effectively, control the uniformity of the particles and enhance the further processing efficiency.
The system is specially designed to process sticky pastes and materials with high moisture content. Mechanical dispersion can be used to process the wet material, which will enable it to get into good contact with hot air and dry quickly.
Spin Flash Drying System can be used to dry crystalline and granular materials, and will not affect their physical characteristics. It offers a controlled drying environment to ensure quality output of the products.
Pharma Spin Flash Dryer is suitable for drying Pharmaceutical intermediates, APIs and Specialty Compounds. It is used to control the operation, which is beneficial in maintaining product purity, quality and moisture levels.
Chemical Spin Flash Dryer is well suited for drying chemical powders, specialty chemicals, polymers, fertilizers and industrial compounds. It is able to deliver efficient drying for various chemical processing applications.
The dryer application is widely used for drying of fine uniform powder products in the pigment & dye industry. It is used for moisture reduction and consistency of products.
Various food ingredients and powder-like products can be dried using the Spin Flash Dryer. The system delivers a controlled drying process to ensure quality, texture and processing requirements.
Efficient Drying of Minerals, Ceramic Powders, Clay-based Materials, and Inorganic Compounds are possible with Industrial Spin Flash Dryer. It ensures reliable performance for heavy-duty industrial applications.
The dryer can be used to process plastic powders, polymer additives and specialty materials. It is used to remove moisture efficiently without affecting product attributes.
Spin Flash Dryer offers fast drying in a short residence time, which is ideal for materials with temperature sensitivity. It minimizes degradation of the product during drying.
Closed Loop Spin Flash Dryer is employed for drying of solvent containing products when controlled processing and recovery of the solvents is desired. It provides safer operation with reduced emissions and product loss.
The system is able to keep drying the powder continuously for large-scale powder production. It enhances productivity, decreases manual handling and provides uniform final product quality.
The Spin Flash Drying System eliminates moisture quickly by offering good contact between the hot air and the moist materials. High speed mechanical dispersion and an effective heat transfer shortens drying time considerably. This makes this system suitable for continuous production processes, where rapid and reliable drying is needed.
The Spin Flash Dryer provides controlled drying conditions to ensure uniform product moisture, particle size and product characteristics. Hot air mixing with the material will be done in a proper manner, which will enable uniform drying during the process. This ensures the quality and production of the product and adherence to the requirements of the industry.
The short residence time in the drying chamber prevents thermal damage of heat sensitive materials. Moisture is taken out efficiently without having to put the product at high temperatures for a long time. The system is suitable for pharmaceutical, chemical and specialty material applications.
The Spin Flash Dryer is a combination particle size reduction, drying and product separation process. This eliminates the need for several pieces of equipment, while also decreasing the amount of manual handling. The closed process also minimizes product contamination and material losses.
The Spin Flash Dryer provides stable and consistent performance over time with continuous operation, enabling high-volume production. Automated feeding and controlled drying parameters help improve process efficiency. It boosts productivity and ensures consistent drying performance.
The system is designed to efficiently transfer heat and distribute airflow optimally, maximizing the use of thermal energy. This speeds up the evaporation of the moisture, thereby minimizing energy wastage. This leads to better operational efficiency and reduction of processing costs.
Because it is the Custom Spin Flash Dryer Manufacturer, the system can be tailored based on the requirements of the production capacity, characteristics of the material and the process itself. There are many options available, including GMP design, stainless steel construction, and closed loop systems, that can address different industry standards.
The enclosed structure of the Spin Flash Dryer reduces dust generation, exposure and contamination risks during the drying process. Advanced collection systems aid in a cleaner processing environment. It will provide safer operation for the industries that are handling sensitive materials or fine powder materials.
Simple and robust construction, allows easy inspection, cleaning and maintenance of the Spin Flash Dryer. The durable parts will provide long service life and minimize unplanned downtime. The design is user-friendly which ensures smooth operation with low maintenance.
The Industrial Spin Flash Dryer can be used in pharmaceuticals, chemicals, food processing, minerals, ceramics, pigments and polymers industry. It can also be used for various industrial applications like drying powders, pastes and wet cakes due to its versatility in handling different shapes and forms of material.
